Belcat Street Box Digital Sound Styling Guitar Amplifier, 15 Watt, Rechargeable

** Specifications **

OUTPUT POWER: RMS 15W(MAX), Min. 8@5% THD, 1KHz

INPUT IMPEDANCE: 470k

SPEAKER: 5.25(Inch) *2 Custom Speaker

TUNER: C1 (32.7Hz) ~ A5 (880Hz)

AC/DC ADAPTER: SMPS DC24V 1.2A (Come with the Amp.)

BATTERY: Rechargeable, Lithium-ion 18.5V 2200mAh charge current 24V 1A. 1 fully charged for over 4 hours using.

BLUETOOTH: 4.0

DIMENSIONS: 25.5~28(H) * 41 (W) * 22 (D) cm

NET WEIGHT: 7.0kg

Operation Manual

** Control Functions **

Power: Turns Amplifier ON / OFF

Simulation Selector: Press to select desired simulated amps.

Save (user memory): To Save up to 8 section control settings(Bass, Middle, Treble, Effect, DLY/REV)

1. Turn on power switch
2. Press button of timbrel simulation to select alphabet space
3. Set what you want
4. Press save button(about 2 seconds) after setting

To reset memory

1. Press Save button continuously and hold
2. Turn on power switch and hold about Save button for about 5 seconds
3. All LED will be blinking by turns, then unpress the button
4. Turn off power switch and turn on power again
5. GAIN: Sets the amount of gain or distortion in the overdrive channel, higher setting provides additional distortion
6. VOLUME: Setting from 0 to full power
7. TREBLE: Controls the boost and cut of the upper frequency range
8. MIDDLE: Controls the boost and cut of the middle frequency range
9. BASS: Controls the boost and cut of the low frequency range
10. MODE: Select Digital Signal Processing effects:
11. CHORUS: Will fatten up the sound of a bass, rhythm guitar, or solo guitar, adds spaciousness
12. FLANGER: This creates a flanging effect, a sort of spinning sensation with the sound
13. PHASER: an electronic sound processor used to filter a signal by creating a series of peaks and troughs in the frequency spectrum
14. TREMOLO: A modulation effect that rhythmically changes the volume of your signal
15. DEL/REV: To change the function among E-ECHO, D-DELAY, M-DELAY, REVERB
16. E-ECHO: Changing the level of ECHO
17. D-DELAY: Changing the time and amount of D-DELAY effects
18. M-DELAY: Changing the time and amount of M-DELAY effects
19. REVERB: To adjust the REVERB level
20. EFFECTS(MODE): To change the level of MODE function
21. EFFECTS(DEL/REV): To change the level of DEL/REV function
22. AUX/BLUETOOTH: Bluetooth input volume settings, from 0 to full power
23. MIC(VOLUME): Adjust the output volume of the Microphone
24. MIC(TONE): Adjust the output tone of the Microphone
25. MIC(ECHO): Adjust the output of the echo sound
26. BLUETOOTH: Turns Bluetooth ON / OFF
27. BASS BOOSTER: Boost a bass sound
28. MODE SWITCH: 5-Mode sound switch Flat-Rock-Pops-Classic-Jazz
29. LOW BATTERY: Green- Fully charged/ Red-Low battery
30. HEADPHONES: To connect stereo headphone. When using the headphone jack, the amplifier speaker is disconnected.
31. AUX IN: To connect for accompaniment or other signals, such like CD player, MP3 player. Non-latching(momentary) Model FST-11
32. SIMUL FTSW: To change Simulation pedal channels
33. GUITAR INPUT: To connect with a guitar
34. CHARGE LED: Red The amplifier is being charged
35. CHARGER: Use DC [email protected] adaptor SMPS (come with the amplifier)
36. MIC INPUT: To connect to microphone
