Go Anywhere,Record Anything
The H1 XLR is the recorder for creators who know no limits. Capture audio for video, direct feeds from mixers, song ideas and more.

More

Input Flexibility
Equipped with two locking XLR/TRS combo inputs the H1 XLR is ready to record microphones, stereo board feeds, instruments and more.

The 3.5mm stereo input allows you to record on-camera mics, lavaliers, phones and other sources.

Never Worry About Gain Again
Plug in, hit record, and capture your audio worry-free. With 32-bit float and dual AD converters, the H1 XLR’s vast dynamic range preserves details in both quiet and loud recordings.

Ultra-Clean Preamps
The H1 XLRs preamps give you crystal clear audio with a -122dB EIN and sample rates up to 96khz.

Line Level Like a Pro
Capture +4dBu professional line level signals to record clip-free audio from any mixer or line output.

Stereo or Mono
The H1 XLR can record both stereo and mono files depending on your application.

Attention Musicians
Capture live band performances or DJ sets by taking a stereo feed from your mixing board.

Perfect On Camera
The H1 XLR is perfect for mounting on your rig to record great audio from shotgun or wireless mics.

The Sound Designers Companion
With 32-bit float recording, you can capture the roar of the loudest engines and the delicate whispers of nature in stunning quality.

Podcast Anywhere
With the H1 XLR and two of your favorite mics its easy to record podcasts anywhere you go.

Perfect Audio for your Mobile Video
Connect the H1 XLR to your mobile device via the USB-C port and record professional audio directly onto your phone’s video. Perfect for video podcasts, live streams, and more.

32-bit Float Audio Interface
Connect to a PC, Mac, iOS, or Android device and use the H1 XLR as an audio interface while simultaneously recording to the SD card.

Accessibility
The H1 XLR is designed with Accessibility for the blind and visually impaired. Navigate the menu with audible descriptions through the built-in speaker or headphones. Creators can choose English, Spanish, French, Japanese, German, Italian or Chinese.*

Features

• Mic/Line Switch
  Flip the switch from mic to line level without having to switch cables.
• Built-in Mixer
  Use the mixer to easily adjust each tracks audio level.
• Waveform display
  The high-contrast OLED screen makes it easy to navigate through the H1 XLRs simple interface.The real-time waveform display lets you see your audio as it records.
• Headphone Output
  Use the 3.5mm headphone output for headphones or to connect directly to a camera.
• Onboard speaker
  Use the onboard speaker to listen to your recordings for quick reference as well as to utilize the accessibility functions.
• High Capacity Storage
  The H1 XLR supports SDXC cards up to 1TB to record days of audio.
• Phantom and Plug-In Power
  Record condenser microphones with phantom power or lavaliers with plug-in power.
• Power Options
  The H1 XLR can be powered by two AA batteries or via the USB-C port. This includes bus-power as well as external USB battery packs.

Specs

• Inputs
  • MIC/LINE (MONO):2 XLR/TRS combo jacks (XLR: 2 HOT, TRS: TIP HOT)
  • MIC/LINE IN Jack: Stereo mini jack
• Outputs
  • PHONE/LINE OUT: Stereo mini jack
  • Built-In Speaker: 20 mm 30 mm elliptical dynamic speaker
• Recorder
  • Format: WAV (44.1, 48 or 96 kHz / 32-bit float), Stereo / Mono, BWF and iXML formats supported
  • Recording media:
    • 4 32GB cards compatible with the microSDHC specification
    • 64GB 1TB cards compatible with the microSDXC specification
• Display: OLED 128×64
• USB Type-C *Use a USB cable that supports data transfer
• Power: 2 AA batteries or AC adapter (ZOOM AD-17: DC 5V / 1A) *USB bus power supported
